Low Voltage Stack Battery ESS TP Series

Product Features：

Support multiple communication and multiple inverter communication matching

Capacity Covering: 10-30KWH

Module Design, light weight, small size

Suitable for long-term charge and discharge cycle

Support connection in parallel and capacity expansion

Easy installation

Message

Portable Power Station

Household ESS Series

Wall Mounted ESS HP Series Low Voltage Stack Battery ESS TP Series High Voltage Stack Battery ESS XP-HV Series On-grid & Off-grid Integrated ESS XP-GV Series

Solar panels

Accessories

Product Details

Product Specification

Model	TP-10KW	TP-15KW	TP-20KW	TP-25KW	TP-30KW
Nominal Voltage	48V/51.2V (optional)
Rated Capacity	200Ah	300Ah	400Ah	500Ah	500Ah
Storage Power	10KWH	15KWH	20KWH	25KWH	30KWH
IR （AC）	≤ 60mΩ
Cycle Life	5000cycles
Design Life	≥10 years
Charging Voltage	53V ± 0.5V ( 15S);56.0V± 0.5V ( 16S)
Max working Current	150A	200A	300A	300A	300A
Discharge Cut-off Voltage	45V± 1.0V ( 15S);48V± 1.0V ( 16S);
Operation Temperature Range	0℃~40℃
Storage Temperature	-20℃~40℃
Size (mm)	483460(510)186	483460(510)372	483460(510)558	483460(510)744	483460(510)930
Weight	110kg	165kg	230kg	285kg	340kg
Communication	RS232 -PC,RS485 (B ) -PC
Communication	RS485 (A ) -Inverter, Canbus -Inverter
Quantity in Parallel	Max 10pcs PACK in parallel
Certification	UN38.3,MSDS,UL1973 (Cell),IEC62619 (Cell)
